The 3500/92 Communication Gateway module provides extensive communication capabilities of all rack monitored values and statuses for integration with process control and other automation systems using both Ethernet TCP/IP and serial (RS232/RS422/RS485) communications capabilities. It also permits Ethernet communications with 3500 Rack Configuration Software and Data Acquisition Software.

Supported protocols include:
Modicon Modbus protocol (via serial communications)
Modbus/TCP protocol (a variant of serial Modbus used for TCP/IP Ethernet communications)
Proprietary Bently Nevada protocol (for communication with 3500 Rack Configuration and Data Acquisition Software packages)

The 3500/92 supports the communication interfaces, communication protocols, and other features from the original 3500/90 with the exception of the primary value Modbus registers. The 3500/92 now has a Configurable Modbus Register Utility, which can provide the same functionality originally addressed by the primary value Modbus registers.

137495-01 Firmware IC (Odd bank)

137494-01 Firmware IC (Even bank)

136180-01 3500/92 Communication Gateway Module.

125736-01 ModbusRS232/RS422 I/O Module.

133323-01 ModbusRS485 I/O Module.

136188-01 Ethernet/RS232 ModbusI/O Module

136188-02 Ethernet/RS485 ModbusI/O Module
