BENTLY 3500/05-01-02-00-01 Frame

BENTLY 3500/05-01-02-00-01 Frame

BENTLY 3500/05-01-02-00-00-01 VMIVME-7807/VME-7807RC VME interface from PCI to VME provides a bridge interface chip built around Tundra Semiconductor company Universe II VME. Universe II offers reliable high performance 64-bit in a design with a VME to PCI interface.

System features and programming based on Universe VME interface BENTLY 136711-01 under the title: The Embedded Systems company is based on Tundra Universe II VME Interface Product Manual (500-000211-000).2C/SMBus Temperature sensor MAX6657MSA can be monitored on the SMBus at address 0x98 for the VMIVME-7807/VME-7807RC. This will allow the user to monitor and set two alerts available (Alert and OVERT1). The VMIVME-7807/VME-7807RC provides non-volatile RAM (NVRAM), timer and clock watchdog timer via PCI bus.

Embedded and real-time applications require these features and this is the time to apply. The PCI configuration space for these embedded functions is as follows: The “Device ID” field indicates that the device is used in VME products (00) and represents: the set of supported embedded features. The “Vendor ID” and “Subsystem Vendor ID” fields indicate that PICMG of the GE Fanuc Embedded system is assigned to the vendor ID (114A). The Subsystem ID field indicates the product model number (7807).
