The Emerson VE4003S2B1 is a high-density traditional I/O module from the DeltaV M-series, designed for robust process automation in demanding industrial environments. This 32-channel analog input module provides 4-20mA/HART signal conditioning with 16-bit resolution, achieving ±0.05% full-scale accuracy. As part of Emerson’s Plantweb™ digital ecosystem, the VE4003S2B1 supports Foundation Fieldbus and PROFIBUS PA integration, enabling seamless data exchange between field devices and DeltaV controllers.
Featuring galvanic isolation up to 1500V between channel groups, this hot-swappable module ensures continuous operation during maintenance activities. The Emerson VE4003S2B1 incorporates Advanced Device Diagnostics (ADD) technology that detects wiring faults and sensor degradation with 1mA resolution. Its -40°C to +70°C operational range makes it suitable for outdoor installations in arctic climates or desert regions.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | VE4003S2B1 |
| Manufacturer | Emerson |
| Product Type | DeltaV M-series Traditional I/O |
| Input Channels | 32×Analog (4-20mA/HART) |
| Resolution | 16-bit |
| Accuracy | ±0.05% FS |
| Isolation | 1500V channel-to-channel |
| Update Rate | 50ms per channel |
| Power Consumption | 3.2W @ 24VDC |
| Communication | Foundation Fieldbus H1, PROFIBUS PA |
| Enclosure Rating | IP40 |
| Operating Temp | -40°C to +70°C |
| Dimensions | 135×110×75mm |
| Weight | 850g |
| Certifications | ATEX, IECEx, SIL2 |
Key Features and Advantages:
Intrinsic safety: The Emerson VE4003S2B1 supports FISCO model installation in hazardous areas (Zone 1/21), reducing explosion-proof enclosure requirements. Its <1μA leakage current prevents ignition risks in petrochemical facilities.
Smart calibration: Automatic zero/span adjustment via HART 7 protocol eliminates manual trim operations. The module stores calibration history for 10,000 cycles in non-volatile memory.
Cybersecurity hardened: Implements Emerson’s Secure First Mile architecture with encrypted device descriptors and signed firmware updates. The hardware-enforced write protection prevents unauthorized configuration changes.
Application Areas:
The Emerson VE4003S2B1 is widely deployed in:
- Chemical processing: Distributed temperature monitoring in reactor farms
- Pharmaceutical: Cleanroom pressure differential control
- Oil & Gas: Wellhead pressure monitoring in offshore platforms
- Power generation: Feedwater flow measurement in boilers
In LNG liquefaction trains, this module handles cryogenic temperature inputs from 200+ RTDs simultaneously. It maintains ±0.1% measurement stability in fertilizer plants where ammonia concentration varies rapidly.
Related Products:
- 8810-HI-TX 8-Channel Safety AI, 4-20mA with HART
- DeltaV Distributed Control System VE3008 MQ Controller
- EMERSON VE3008 CE3008 KJ2005X1-MQ1 12P6381X042 Module card
- EMERSON 1C31113G01 Digital output module (5-60VDC)
- 8851-LC-MT Remote I/O PAC8000
- EMERSON 5X00875G01 Ovation OCR3000 Controller Atom CPU Module
- Emerson SLS1508 KJ2201X1-BA1 Security logic solver module
Installation and Maintenance:
Installation preparation: Verify backplane voltage (18-30VDC) before installing the Emerson VE4003S2B1. Use Belden 3079F or equivalent shielded twisted pair cables for HART signals. Maintain 50mm clearance from high-voltage conduits.
Maintenance recommendations: Perform channel integrity tests quarterly using DeltaV Operate software. Clean terminal contacts annually with electronic-grade isopropyl alcohol. Replace internal capacitors after 80,000 operational hours (P/N B00344G01).
