IS420UCSCH2A-C-V0.1-A Interface module writes “1” into the START conversion sequence SETTING and EN START CONV control bits, which consist of the following consecutive intervals: a. Settlement delay b.
Tracking interval c. Analog-to-digital conversion Execution All ADC timing intervals discussed in this section are automatically controlled by an on-board intelligent controller.
The program control of the converter consists of a basic handshake sequence.
The stabilization delay occurs directly in the analog network (e.g. selecting a new input channel) and represents the stabilization time of the network. After the settlement delay is complete, the tracking Hold (T&H) amplifier (see Figure 1.2-1) enters the tracking mode and the tracking interval begins.
