METSO IOP302 Industrial control module

METSO IOP302 Industrial control module

METSO IOP302 Connecting multiple drives requires the use of a branch unit, which allows: For the construction of a logical bus with a physical topology, see Figure 60 172 on page. Branch units can be linked. Drive connection supports the following drives: ACS 600 Single drive ACS 600 multi-drive

ACS 600 Thyristor Power Unit ACS 600 IGBT Power Unit ACS 800 Product Family ACS 140-AC S400DCS 600 and DCS 400ACS 6000 Product family/Large driver AC The power system configuration of the 800M controller is very complex and straightforward configuration Figure 61 on page 177 and Figure 62 on page 178 give a series of diagrams showing the various possibilities of connecting the input power – via the power circuit breaker,

the power supply unit and the SS83X voting unit – to the 24 volt DC distribution terminal. The AC 800M controller and its I/O system are usually located in one or more locations housing or cabinets. The cabinet where the AC 800M controller is installed can also: contain a communication interface for the I/O unit Optical Fiber module bus or PROFIBUS DP connected to the controller via the electrical module bus
