METSO IOP303 Cabinet containing AC 800M controller This cabinet may require the following power supplies: Power Supply devices: Power the electronic circuits of each device in the cabinet.

Power supply for field devices: Power supply for devices, relay contacts, etc., outside the cabinet, but connected to the input/output of the I/O unit in the cabinet Cabinet strongly recommends: Use a power supply in each cabinet to power the unit (only if the cabinet and the maximum cable length is less than 10m, is the power supply for the device available from another cabinet Use a separate power supply to power the device (including the S800 cluster modem) and to power the field device cabinet containing the I/O system If no other information is provided in the I/O, Use the recommended system documentation above.

This power supply is only connected to the units in the cabinet, such as the PM8XX, and also powers all communication interfaces (via the CEX bus) and all S800 I/O units connected to their electrical module bus. The BC810 powers all communication interfaces connected to its own network segment. The TB820V2/TB840 (optical modem for the S800 I/O), also powers all the I/O units connected to its electrical module bus.
