introduce

This document provides general information, hardware preparation, installation instructions, and function description of the MVME761-001 and MVME761-011 transition modules

The MVME761-0x1 Transition module provides interfaces between the MVME260x, MVME270x, MVME360x, and MVME60x single-board computer VMEodule and various peripheral devices. The module provides industry standard connectors to simplify customer cable requirements for serial ports, printers, and Ethernet signals

The features of the MVME761-0x1 transition module include:

[Industry standard connectors for these interfaces]

2 EIA-574 Asynchronous Serial Ports (DTE)

-2 asynchronous/synchronous serial ports with EIA-232-D, EIA-530, V.35 or X.21 interfaces (DCE or DTE) and one parallel port (according to IEEE standard 1284-1)

10Base-T/100Base-TXLl Large network

[Two 60-pin SIM(Serial lnterface Module) connectors for configuring asynchronous/synchronous serial ports

[single width plate]

[Electromagnetic Interference (EMI) and electrostatic discharge (ESD) protection
