SR745 series SR745-W2-P1-G1-HI-A-L-R Generator Management Relay
Economical protection, metering, and monitoring functions for small and medium sized generators.
The SR745-W2-P1-G1-HI-A-L-R Generator Management relay is a high-performance protective relay manufactured by GE Multilin and designed for protection and control applications in power systems. The relay belongs to the GE Multilin 489 series, which is in the same family as the GE Multilin 469 motor protection relay and the GE Multilin 735 feeder protection relay
SR745-W2-P1-G1-HI-A-L-R Specifications:
◆ Model: SR745-W2-P1-G1-HI-A-L-R
◆ Manufacturer: GE Multilin
◆ Application scenario: power system protection and control
Main characteristics
◆ Voltage and frequency options
◆ Multiple voltage options
◆LO control power: 20-50 VDC, 48-72 VAC at 20-68 Hz
◆ Size and weight: 21.6cm x 222.4cm x 25.2cm, 10kg
◆ Analog output: 4 to 20mA
◆ Display and panel: 40-character display, including multiple status leds, input buttons, etc
Technical parameter
◆ Working voltage: 120v ac / 50/60hz
◆ Communication function: optional Ethernet port
◆ Input/output configuration: four isolated 4-10 mA analog inputs and outputs and seven assignable digital inputs
Application field
◆ Generator protection
◆ Can be used for induction or synchronous generator
Other information
◆ Protection, measurement and monitoring functions
◆ Support microprocessor or solid state relay configuration
