SUE 3000 High Speed Switching Device (HSTD)
SUE3000 1VCR007346 G0032 High Speed Switching Device (HSTD)
The SUE3000 1VCR007346 G0032 High Speed Transfer Device can be implemented everywhere where a disturbance of the electrical supply would lead to a breakdown in production, which would lead as a result to costs.Possible areas of utilization include, for example: Auxiliary installations serving power stations, as for example，Steam power stations，Gas turbine power stations，Combined cycle power stations，Nuclear power stations.
Main advantages of SUE3000 high speed switching device
1: Reliable, safe and uninterrupted power supply for electrical equipment
2: Improve plant equipment utilization and prevent costly production disruptions
3: Compatible with all voltage levels
4: Compared with UPS systems, investment and operating costs are lower, and installation is easier
5: Small mechanical installation space requirements
6: Easy integration of existing and new switchgear
Main features of SUE3000 high speed switching device
1: Four switching modes with different configurations
2: Suitable for two to three circuit breaker configurations
3: Flexible communication protocols (IEC 61850-8-1, SPA bus, LON, Modbus RTU, IEC 60870-5-103, Ethernet interface, Web server, Profibus DP)
4: With fault recording function and watchdog self-test function
5: With high-speed exit
6: Integrate various security functions, such as coil monitoring and decoupling functions
ABB Product recommendations: Analyzer module AO2000-LS25 Laser analyzers ，GFD563A102 3BHE046836R0102丨AC800 PEC丨Performance controller rectifier field ，Transmission system PFSA103D 3BSE002492R0001 Signal transmission unit ，Panel 800 version 6 PP877 3BSE069272R2 Operator panel，SUE3000 1VCR007346 G0032
SUE 3000 High Speed Transfer Device Parameter specifications
Rated current IN： 1 A or 5 A
Rated voltage UN： 100 V … 125 V
Rated frequency fN： 50 Hz / 60 Hz
Current path： 250 IN (peak value) 100 IN (dyn.) für 1 s 4 IN continuous
Voltage path： 2 UN/√3 continuous
Current path： 0.1 VA with IN
Voltage path： 0.25 VA with UN
Input voltage： 48 … 265 V DC /
110 … 265 V DC
(Threshold 35 V DC or 75 V DC)
Number of power outputs： 2 per board
Operating voltage： 48 … 265 V DC
Making current： 70 A (t ≤ 10 ms)
Load current： 12 A (t ≤ 30 s)
