TRICONEX MP3101 Main Processor Modules

The Triconex Tricon Safety Instrumented System is designed to meet the needs of safety and critical control applications in oil and gas, power, refining, chemicals, pharmaceutical and biotech industries.
It is based on industry leading TMR technology, is easy to operate and maintain and provides the lowest total cost of ownership.

Models 3502E, 3503E, and 3505E can self-test to detect stuck-On conditions where the circuitry cannot tell whether a point has gone to the Off state.  Since most safety systems are set up with a deenergize-to-trip capability, the ability to detect Off points is an important feature.  To test for stuck-On inputs, a switch within the input circuitry is closed to allow a zero input (Off) to be read by the optical isolation circuitry.  The last data reading is frozen in the I/O communication processor while the test is running.

Main Processor Modules:

3008 Main Processor, 16 megabytes DRAM  Triconex3008

Communication Hardware and Software:

Tricon Communication Module (TCM), Ethernet (802.3) and serial (RS-232/RS-485) ports

4351A, Triconex4352A,

4351B, Triconex4352B

4353, Triconex4354

Enhanced Intelligent Communication Module (EICM), serial (RS-232/RS-422/RS-485) ports  Triconex4119, Triconex4119A

Safety Manager Module (SMM), Honeywell UCN Interface  Triconex4409

Network Communication Module (NCM), Ethernet (802.3) ports  Triconex4329, Triconex4329G

Advanced Communication Module (ACM), Foxboro I/A Series Nodebus Interface  Triconex4609

Hiway Interface Module (HIM), Honeywell Data Hiway Interface  Triconex4509

Triconex DDE Server Software  Triconex7523-2

Network Accessory Kit (Ethernet thin cable, connectors and terminators)  Triconex7600-3

Remote Extender Modules:

1:Primary RXM, Multi-Mode Fiber Optics, Set of 3 Modules  Triconex4200-3

2:Remote RXM, Multi-Mode Fiber Optics, Set of 3 Modules  Triconex4201-3

3:Primary SRXM, Single-Mode Fiber Optics, Set of 3 Modules  Triconex4210-3

4:Remote SRXM, Single-Mode Fiber Optics, Set of 3 Modules   Triconex4211-3

Interface Modules:

Triconex2770H HART Analog Input Interface Module with 2071H HART Multiplexer

HART Analog Input Interface Module with 2071H HART Multiplexer and Amp-Elco Adapter Cable Triconex2750-2H

2870H HART Analog Output Interface Module with 2071H HART Multiplexer Triconex2870H

HART Multiplexer  Triconex2071H

Chassis Assemblies:
Main Chassis, High-Density Configuration, includes the Tricon printed manuals  Triconex8110
Expansion Chassis, High-Density Configuration  Triconex8111

Expansion Chassis, Enhanced Low-Density Configuration  Triconex8121

Remote Expansion Chassis, High-Density Configuration  Triconex8112

I/O Bus Expansion Cables (Set of 3)  Triconex9000

I/O-COMM Bus Expansion Cables (Set of 3)  Triconex9001

Blank I/O Slot Panel  Triconex8105
