WINGREEN 03ZSTI2-00-501-R is a digital signal processor (DSP) module for data processing and control functions in industrial control systems. It provides high performance signal

processing capabilities to perform complex algorithms and real-time data processing tasks.
Processor 25 MHz 32-bit MC68040 or MC68LC040 microprocessor DRAM 1 or 4MB shared DRAM with parity protection on the sandwich module; 4, 8, 16, or 32MB shared DRAM with ECC protection on a sandwich board please note the following known issues and their solutions: When the RESET button on the 03ZSTI2-00-501-RS series board is held down for more than a minimum length of time, parity DRAM refresh may be disabled and memory contents may be lost.

This length of time may vary from board to board, as well as depending on environmental conditions! Warning: If you intend to check the memory after the reset, release the reset button as soon as possible after pressing the reset button to ensure that the parity DRAM content has not been changed. Note: On 200/300 series boards, ECCprotected DRAM is protected by parity check. Information on parity DRAM is given in the MCchip chapter of this guide, https://www.saulbonnie.com/and ECC DRAM is given in the MCECC chapter.

In later versions, 700/800 series parity is not supported on non-ECC DRAM, and 03ZSTI2-00-501-RS currently has parity on only one board in the series. Parity must remain disabled on all 700/800 sequence boards.)
