6U VME Dual Axis Measurement Board
ZYGO ZMI-2002 8020-0211 6U VME Dual Axis Measurement Board
ZYGO ZMI-2002 8020-0211 6U VME Dual Axis Measurement Board
The laser source may be the single most critical component of the Displacement Measuring Interferometer. To control and assure laser head quality, Zygo manufactures our own laser tubes. The proprietary tube design, combined with a state-of-the-art assembly and test facility, provides for a highly reliable laser head with:
• > 50,000 hour lifetime,
• Longest basic warranty at 18 months,
• Extended warranties of up to 5 years,
• Up to 8 axes of interferometry on a single head,
• Multiple head synchronization.
# of Axes per Board 1 (ZMI 2001, ZMI PC) / 2 (ZMI 2002)
Power Requirement +5V ± 5% @ 3.5A (ZMI 2001, ZMI 2002, ZMI PC)
+12V ± 10% @ 0.1A (ZMI PC)
Position Format 36 bit – 2’s complement
Velocity Format 32 bit – 2’s complement
Time Range 107.4 seconds
Time Format 32 bit – 2’s complement
Time Resolution 25 ns
Fiber Optic Signals Reference and Measurement
Error Status Reference (signal, PLL, DLL)
Measure (Missing, Dropout, Glitch)
Velocity (Board, User Defined)
Acceleration
Overflow (32 bit, 36 bit)
System Synchronization Clock in or Clock out
ZMI VME Compliance VMEBus specification revision C.1
6U size
A16 or A24 addressing
D16 or D32 data transfer
D08 (0) interrupt acknowledge cycle
ZMI PC Compliance UL94V0
Full length ISA card
16 bit ISA bus
32 bit P2 bus
